Quasar SP-2725F User Manual

-8-
Parts List
REPLACEMENT PARTS LIST
Models: SP-2725F, SP-2725UF
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
065-02
PARTS LIST
REF
NO.
PART NO. DESCRIPTION
CAPACITORS
C001 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C002 TCJ2VB1H471K CAP,C 470PF-K-50V
C003 ECA1HM4R7B CAP,E 4.7UF-50V
C004 TCJ2VC1H150J CAP,C 15PF-J-50V
C005 TCJ2VC1H150J CAP,C 15PF-J-50V
C008 TCJ2VF1H104Z CAP,C .1UF-Z-50V
C009 ECA1AM470B CAP,E 47UF-10V
C010 TCJ2VF1H104Z CAP,C .1UF-Z-50V
C011 ECA1AM101B CAP,E 100UF-10V
C015 ECJ2VB1C224K CAP,C .22UF-K-16V
C016 TCJ2VC1H101J CAP,C 100PF-J-50V
C017 TCJ2VB1C104K CAP,C .1UF-K-16V
C018 TCJ2VC1H151J CAP,C 150PF-J-50V
C020 TCJ2VB1C104K CAP,C .1UF-K-16V
C022 TCJ2VC1H101J CAP,C 100PF-J-50V
C023 TCJ2VC1H151J CAP,C 150PF-J-50V
C024 ECA1AM470B CAP,E 47UF-10V
C025 TCJ2VB1C104K CAP,C .1UF-K-16V
C026 TCJ2VB1C104K CAP,C .1UF-K-16V
C027 TCJ2VF1H104Z CAP,C .1UF-Z-50V
C028 TCJ2VB1C104K CAP,C .1UF-K-16V
C029 ECQB1H333JF3 CAP,P .033UF-J-50V
C031 ECA1HMR22B CAP,E .22UF-50V
C032 ECA1AM470B CAP,E 47UF-10V
C033 TCJ2VC1H390J CAP,C 39PF-J-50V
C034 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C035 ECA1HM010B CAP,E 1UF-50V
C036 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C037 ECA1HM0R1B CAP,E 0.1UF/50V
C038 ECA1AM470B CAP,E 47UF-10V
C040 ECA1AM470B CAP,E 47UF-10V
C041 ECA1HM2R2B CAP,E 2.2UF-50V
C042 TCJ2VF1H104Z CAP,C .1UF-Z-50V
C043 ECA1AM470B CAP,E 47UF-10V
C044 TCJ2VC1H471J CAP,C 470PF-J-50V
C045 ECA1HM0R1B CAP,E 0.1UF/50V
C046 TCJ2VB1C104K CAP,C .1UF-K-16V
C047 TCJ2VC1H220J CAP,C 22PF-J-50V
C048 TCJ2VC1H220J CAP,C 22PF-J-50V
C050 ECA1AM101B CAP,E 100UF-10V
C051 TCJ2VF1H104Z CAP,C .1UF-Z-50V
C055 TCJ2VC1H560J CAP,C 56PF-J-50V
C103 ECA0JM331B CAP,E 330UF-6.3V
C104 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C105 ECA0JM101B CAP,E 100UF-6.3V
C350 ECA1CM101B CAP,E 100UF/16V
C351 TCJ2VB1H391K CAP,C 390PF-K-50V
C352 TCJ2VB1H391K CAP,C 390PF-K-50V
C353 TCJ2VB1H471K CAP,C 470PF-K-50V
C354 ECKW3D102KBN CAP,C .001UF-K-2KVDC
C357 EEANA1E1R0B CAP,E 1.0UF-25V
C361 TCJ2VC1H151J CAP,C 150PF-J-50V
C362 TCJ2VC1H151J CAP,C 150PF-J-50V
C363 TCJ2VC1H151J CAP,C 150PF-J-50V
C451 ECA1CHG470B CAP,E 47UF-16V
C452 ECSF1EE105VB CAP,E 1.0UF-25V
C453 ECEA1HFS010B CAP,E 1UF-50V
C454 ECA1EM102E CAP,E 1000UF-25V
C455 ECA1VHG101B CAP,E 100UF-35V
C456 ECQB1H103JF3 CAP,P .01UF-J-50V
C459 ECA1VHG471B CAP,E 470UF-35V
C462 ECA1HM4R7B CAP,E 4.7UF-50V
C502 TCJ2VC1H471J CAP,C 470PF-J-50V
C503 TCJ2VB1C104K CAP,C .1UF-K-16V
C504 TCJ2VB1C104K CAP,C .1UF-K-16V
C510 ECCR2H100D5 CAP,C 10PF-D-500V
C511 ECKR2H821KB5 CAP,C 820PF-K-500V
C512 ECKR2H101KB5 CAP,C 100UF-K-500V
C531 ECA1EM220B CAP,E 22UF-25V
C551 ECA1VM331B CAP,E 330UF-35V
C554 ECKR2H561KB5 CAP,C 560PF-K-500V
C555 ECA2EM220E CAP,E 22UF-250V
C556 ECA1CM471B CAP,E 470UF-16V
C557 ECKR2H102KB5 CAP,C 1000PF-K-500V
C560 ECEA1HN010UB CAP,E 1UF/50V
C561 ECKR2H561KB5 CAP,C 560PF-K-500V
C563 ECWH12H822JS CAP,P .0082UF-J-1.2KV
C564 ECWH12H562JS CAP,P .0056UF-J-1.2KV
C565 ECKW3D181JBP CAP,C 180PF-J-2KV
C566 ECKW3D181JBP CAP,C 180PF-J-2KV
C568 ECWF2274JBB CAP,M .27UF-J-200V
C569 ECWF2474JBB CAP,M .24UF-J-200V
C570 ECA1CM222E CAP,E 2200UF-16V
C571 ECA1EM220B CAP,E 22UF-25V
C572 ECA1CM100B CAP,E 10UF-16V
C573 ECA1CM101B CAP,E 100UF/16V
C575 ECA0JM222B CAP,E 2200UF-6.3V
C577 ECA1CM101B CAP,E 100UF/16V
C578 ECA0JM332B CAP,E 3300PF-6.3V
C579 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C580 ECKR2H152KB5 CAP,C 1500PF-K-500V
C605 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C606 ECA0JM221B CAP,E 220UF-6.3V
C801 ECKWAE472ZED CAP,C 4700PF-Z-500V
C802 ECKWAE472ZED CAP,C 4700PF-Z-500V
C803 ECKWAE472ZED CAP,C 4700PF-Z-500V
C805 EC0S2DA331BB CAP,E 330UF/200V
C806 ECQM4103KZW CAP,P .01UF-K-400V
C807 ECKR3A821KBP CAP,C 820PF-K-1KV
REF
NO.
PART NO. DESCRIPTION
