Quasar SP-2725F User Manual

-12-
Parts List
REPLACEMENT PARTS LIST
Models: SP-2725F, SP-2725UF
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
065-02
PARTS LIST
R563 ERG1SJ150P RES,M 15-J-1W
R572 ERJ6GEYJ152V RES,M 1.5K-J-1/10W
R605 ERDS2TJ103T RES,C 10K-J-1/4W
R606 ERJ6GEYJ562V RES,M 5.6K-J-1/10W
R607 ERJ6GEYJ102V RES,M 1K-J-1/10W
R608 ERJ6GEYJ104V RES,M 100K-J-1/10W
R801 ERF7ZK1R5 RES,W 1.5-K-7W
R802 ERDS2TJ684T RES,C 680K-J-1/4W
R803 ERG2FJ100H RES,M 10K-J-1/2W
R804 ERG2FJ104H RES,M 100K-J-2W
R805 ERX2FZJR18H RES,M .18-J-2W
R806 ERX2FJR56H RES,M .56-J-2W
R807 ERDS2TJ681T RES,C 680-J-1/4W
R808 ERDS2TJ4R7T RES,C 4.7-J-1/4W
R809 ERDS2TJ472T RES,C 4.7K-J-1/4
R815 ERC12ZGM825D RES,S 8.2MEG-M-1/2
R821 ERDS1FJ1R0T RES,C 1.0-J-1/2W
R822 ERDS1FJ1R0T RES,C 1.0-J-1/2W
R823 ERDS1FJ272T RES,C 2.7K-J-1/2W
R824 ERDS2TJ223T RES,C 22K-J-1/4W
R825 ERDS2TJ272T RES,C 2.7K-J-1/4W
R828 ERJ6GEYJ104V RES,M 100K-J-1/10W
R830 ERDS2TJ104T RES,C 100K-J-1/4W
R831 ERDS2TJ682T RES,C 6.8K-J-1/4W
R850 ERQ12HJR56P RES,F .56-J-1/2W
R2201 ERJ6GEYJ224V RES,M 220K-J-1/10W
R2203 ERJ6GEYJ102V RES,M 1K-J-1/10W
R2204 ERJ6GEYJ102V RES,M 1K-J-1/10W
R2205 ERJ6GEYJ101V RES,M 100-J-1/10W
R2206 ERJ6GEYJ273V RES,M 27K-J-1/10W
R2301 ERQ2CJP3R9S RES,F 3.9-J-2W
R2307 ERJ6GEYJ103V RES,M 10K-J-1/10W
R2350 ERDS2TJ391T RES,C 390-J-1/4W
R2351 ERJ6GEYJ562V RES,M 5.6K-J-1/10W
R2352 ERJ6GEYJ683V RES,M 68K-J-1/10W
R2353 ERJ6GEYJ124V RES,M 120K-J-1/10W
R2354 ERJ6GEYJ123V RES,M 12K-J-1/10W
R2355 ERJ6GEYJ222V RES,M 2.2K-J-1/10W
R2356 ERJ6GEYJ101V RES,M 100-J-1/10W
R2357 ERJ6GEYJ472V RES,M 4.7K-J-1/10W
R2365 ERDS2TJ102T RES,C 1K-J-1/4W
R2370 ERJ6GEYJ103V RES,M 10K-J-1/10W
R3001 ERDS2TJ101T RES,C 100-J-1/4W
R3005 ERJ6GEYJ334V RES,M 330K-J-1/10W
R3007 ERJ6GEYJ151V RES,M 150-J-1/10W
R3008 ERJ6GEYJ151V RES,M 150-J-1/10W
R3009 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R3010 ERJ6GEYJ334V RES,M 330K-J-1/10W
R3011 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R3013 ERJ6ENF75R0V RES,M 75.0-F-1/10W
REF
NO.
PART NO. DESCRIPTION
R3014 ERJ6ENF75R0V RES,M 75.0-F-1/10W
R3050 ERJ6GEYJ101V RES,M 100-J-1/10W
R3051 ERJ6GEYJ101V RES,M 100-J-1/10W
SWITCHES
S001 EVQPF106K SWITCH
S002 EVQPF106K SWITCH
S003 EVQPF106K SWITCH
S004 EVQPF106K SWITCH
S005 EVQPF106K SWITCH
S008 EVQPF106K SWITCH
S009 EVQPF106K SWITCH
TRANSFORMERS
T501 TLH15452
TRANSFORMER, HORIZONTAL
DRIVER
T551 KFT4AA348F2 TRANSFORMER, FLYBACK
T801 ETS35AA5E3NC TRANSFORMER
CRYSTALS / FILTERS
X001 TSSA092 CRYSTAL OSCILLATOR
X002 AF080005BE CRYSTAL
OTHERS
TNR001 ENG36604GR TUNER
M001 TSX2AA0281 A/C LINE CORD
M002 M68LGL061X CRT 27”
M003 TJSC00300 CRT SOCKET
DY TLY2AA006 DEFLECTION YOKE
M004 JH291U-009 YOKE, CONVERGENCE
DEG TLK2AA0011 COIL, DEGAUSSING
M005 0FMK014ZZ
CONVERGENCE CORRECTOR
STRIP
M006 TMM2A30702 WEDGE, YOKE
M007 TXF3A01ZERA ASSY., DAG GND
M008 TAS2AA0010 SPEAKER 16-OHM 3W
M009 TBX2AA1301G BUTTON, 7-KEY
M010 TKX2A3756 GUIDE, IR
M011 TMW2A97121 STRAIN RELIEF: AC LINE CORD
M012 TKP2AA00601 SMOKED SHEET
M013 TXFKU17BSER
ASSY, CABINET BACK (Cabinet Back,
Felt, Label X-Ray Warning, Label FCC,
Double Insul. Label)
M014 TXFKY02FSER
ASSY, CABINET FRONT (Cabinet
Front, NamePlate Quasar, Smoke
Sheet, Guide IR,(2) Pad Foam, Label
Service Information)
JK3001 TJB2A9064B ASSY. JACK A/V
JK3003 TJB2AA0171 TERMINAL, S-VHS
ACCESORIES
M015 EUR511514 TRANSMITTER, REMOTE CONTROL
M016 UR51EC975A
BATTERY COVER, REMOTE
CONTROL
M017 TQB2AA0379 MANUAL, OWNERS
REF
NO.
PART NO. DESCRIPTION

Quasar SP-2725F Specifications
