The lamps and lanterns use DMX512 signal control model, the control signal of lamps and lanterns
is a parallel relationship, the connection is more than one signal lamps and lanterns, it is best to use
double core shielded cables. Connection, all through the lamps and lanterns of lamps and lanterns
DMX signal on jack (context) INPUT (INPUT) and OUTPUT (OUTPUT) are connected, connect the
line of lamps and lanterns 3 core XLRXL plug terminal must correspond to each other, when the con-
nection signal lamps and lanterns, it is recommended to use DMX signal terminal. Can be avoided,
due to electrical noise damage control signal, DMX signal terminal device is a XLR plugs connection
between 2 and 3 feet a 120 ohm resistance of 1 w, and connect it on the last stage of lamps and
lanterns of the OUTPUT (OUTPUT) jack.
1. The international standard control signal: DMX512
2. The number of channels: 16Ch
3. The number of motor: a total of 10 mute motor
4. The X axis rotate for 540°, the Y axis vertical rotation of 270°, with automatic correction
5. The dimming: 0-100% linear adjustment
6. Stroboscopic: Double chip stroboscopic (0.5-9 times/SEC), completely linear dimming and
variable stroboscopic speed
7. Color wheel: With 14 kinds of color + blank (can create sharp air beam effect)
8. Pattern wheel: With a 17 xed pattern piece + blank (lets you quickly change the beam shape)
9. A prism: Rotating eight prism, can be bi-directional rotation, rotation speed is adjustable, making
a richer pattern projection effect
10. Itemization: Soft light effect, the design of soft dream effect
11. Focus: adopting the combination of three groups of optical lens effect is much better than the
beam of light, usually can reects the pattern of hid
12. The beam Angle: Parallel beam Angle 0° - 3.8°
13. Overheating intelligent protection
14. Smart bulb switch control, prolong the service life of the bulb
Function Description:
Connection of DMX512 signal:
