default value 10 = 10%
0 - reporting disabled
1 - 100 = 1% - 100% reporting enabled
Power report is send (push) only when actual power
in Watts in real time changes for more than set
percentage comparing to previous actual power in
Watts, step is 1%.
NOTE: if power changed is less than 1W, the report is not
send (pushed), independent of percentage set.
Parameter no. 42 – Power reporting in Watts by time
interval
Set value means time interval (0 – 32535) in seconds,
when power report is send. Available configuration
parameters (data type is 2 Byte DEC):
default value 300 = 300s
0 - reporting disabled
1 - 32535 = 1second - 32535 seconds.
Reporting enabled. Power report is send with time
interval set by entered value.
Parameter no. 63 – Output Switch selection
Set value means the type of the device that is connected to
the output. The device type can be normally open (NO) or
normally close (NC). Available configuration parameters
(data type is 1 Byte DEC):
default value 0
0 - When system is turned off the output is 0V (NC).
1 - When system is turned off the output is 230V or
24V (NO).
Parameter no. 100 – Enable / Disable Endpoints I2 or
select Notification Type and Event
Enabling I2 means that Endpoint (I2) will be present on UI.
Disabling it will result in hiding the endpoint according to
the parameter set value. Additionally, a Notification Type
and Event can be selected for the endpoint. Available
configuration parameters (data type is 1 Byte DEC):
Endpoint device type selection:
- notification sensor (1 - 6):
GENERIC_TYPE_SENSOR_NOTIFICATION,
SPECIFIC_TYPE_NOTIFICATION_SENSOR
default value 0
1 - Home Security; Motion Detection, unknown loc.
2 - Carbon Monoxide; Carbon Monoxide detected,
unknown location.
3 – Carbon Dioxide; Carbon Dioxide detected,
unknown location.
4 - Water Alarm; Water Leak detected, unknown lo.
5 - Heat Alarm; Overheat detected, unknown loc.
6 - Smoke Alarm; Smoke detected, unknown loc.
0 - Endpoint, I2 disabled
- sensor binary (9):
GENERIC_TYPE_SENSOR_BINARY,
SPECIFIC_TYPE_NOT_USED
9 - Sensor binary
NOTE1: After parameter change, first exclude module
(without setting parameters to default value) then wait at
least 30s and then re include the module!
NOTE 2: When the parameter is set to value 9 the
notifications are send for Home Security.
Parameter no. 101 – Enable / Disable Endpoints I3 or
select Notification Type and Event
Enabling I3 means that Endpoint (I3) will be present on UI.
Disabling it will result in hiding the endpoint according to
the parameter set value. Additionally, a Notification Type
and Event can be selected for the endpoint. Available
configuration parameters (data type is 1 Byte DEC):
Endpoint device type selection:
- notification sensor (1 - 6):
GENERIC_TYPE_SENSOR_NOTIFICATION,
SPECIFIC_TYPE_NOTIFICATION_SENSOR
default value 0
1 - Home Security; Motion Detection, unknown loc.
2 - Carbon Monoxide; Carbon Monoxide detected,
unknown location.
3 - Carbon Dioxide; Carbon Dioxide detected,
unknown location.
4 - Water Alarm; Water Leak detected, unknown lo.
5 - Heat Alarm; Overheat detected, unknown loc.
6 - Smoke Alarm; Smoke detected, unknown loc.
0 - Endpoint, I3 disabled
- sensor binary (9): GENERIC_TYPE_SENSOR_BINARY,
SPECIFIC_TYPE_NOT_USED
9 – Sensor binary
NOTE1: After parameter change, first exclude module
(without setting parameters to default value) then wait at
least 30s and then re include the module!
NOTE 2: When the parameter is set to value 9 the
notifications are send for Home Security.
Parameter no. 110 – Temperature sensor offset
settings
Set value is added or subtracted to actual measured value
by sensor. Available configuration parameters (data type is
2 Byte DEC):
default value 32536
32536 - offset is 0.0C
From 1 to 100 - value from 0.1°C to 10.0°C is added
to actual measured temperature.
From 1001 to 1100 - value from -0.1 °C to -10.0 °C is
subtracted to actual measured temperature.
Parameter no. 120 –Temperature sensor reporting
If digital temperature sensor is connected, module reports
measured temperature on temperature change defined by
this parameter. Available configuration parameters (data
type is 1 Byte DEC):
default value 5 = 0,5°C
0 - Reporting disabled
1- 127 = 0,1°C – 12,7°C, step is 0,1°C
Technical Specifications
110 - 230 VAC ±10%
50/60Hz, (24-30VDC)
Rated load current of AC
output (resistive load)*
Output circuit power of AC
output (resistive load)
Output circuit power of DC
output (resistive load)
Power measurement
accuracy
P=5-50W, +/-3W
P>50W, +/-3%
Digital temp. sensor range
(must be ordered separately)
Dimensions (WxHxD)
(package)
41,8x36,8x15,4mm
(79x52x22mm)
Weight (Brutto with package)
For installation in boxes
Ø ≥ 60mm or 2M,
depth≥ 60mm
* In case of load other than resistive, pay attention to the
value of cos φ and if necessary apply load lower than the
rated load. Max current for cos φ=0,4 is 3A at 250VAC, 3A
at 24VDC L/R=7ms.
Supported loads:
Conventional incandescent and halogen lights
LED bulb, compact fluorescent bulb (CFL), low
voltage halogen bulbs with electronic transformer
Low voltage halogen bulbs with conventional
transformer
Z-Wave Device Class:
ZWAVEPLUS_INFO_REPORT_ROLE_TYPE_SLAVE_ALWAYS_0N
GENERIC_TYPE_SWITCH_BINARY
SPECIFIC_TYPE_POWER_SWITCH_BINARY
Z-Wave Supported Command Classes:
COMMAND_CLASS_ZWAVEPLUS_INFO_V2,
COMMAND_CLASS_VERSION_V2,
COMMAND_CLASS_MANUFACTURER_SPECIFIC_2,
COMMAND_CLASS_DEVICE_RESET_LOCALLY_1,
COMMAND_CLASS_POWERLEVEL_V1,
COMMAND_CLASS_BASIC_V1,
COMMAND_CLASS_SWITCH_ALL_V1,
COMMAND_CLASS_SWITCH_BINARY_V1,
COMMAND_CLASS_SENSOR_BINARY_V1,
COMMAND_CLASS_METER_V4,
COMMAND_CLASS_SENSOR_MULTILEVEL_V7,
COMMAND_CLASS_MULTI_CHANNEL_V4,
COMMAND_CLASS_ASSOCIATION_V2,
COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3,
COMMAND_CLASS_ASSOCIATION_GRP_INFO_V2,
COMMAND_CLASS_CONFIGURATION_V1,
COMMAND_CLASS_MARK,
COMMAND_CLASS_BASIC_V1
Endpoint 1
Device Class:
ZWAVEPLUS_INFO_REPORT_ROLE_TYPE_SLAVE_ALWAYS_0N
GENERIC_TYPE_SWITCH_BINARY
SPECIFIC_TYPE_POWER_SWITCH_BINARY
Command Classes:
COMMAND_CLASS_ZWAVEPLUS_INFO_V2
COMMAND_CLASS_VERSION_V2
COMMAND_CLASS_BASIC_V1
COMMAND_CLASS_SWITCH_ALL_V1
COMMAND_CLASS_SWITCH_BINARY_V1
COMMAND_CLASS_METER_V4
COMMAND_CLASS_ASSOCIATION_V2
COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3
COMMAND_CLASS_ASSOCIATION_GRP_INFO_V2
COMMAND_CLASS_MARK
COMMAND_CLASS_BASIC_V1
Endpoint 2 (I2):
Device Class:
ZWAVEPLUS_INFO_REPORT_ROLE_TYPE_SLAVE_ALWAYS_0N
GENERIC_TYPE_SENSOR_NOTIFICATION
SPECIFIC_TYPE_NOTIFICATION_SENSOR
Command Classes:
COMMAND_CLASS_ZWAVEPLUS_INFO
COMMAND_CLASS_VERSION_V2
COMMAND_CLASS_SENSOR_BINARY
COMMAND_CLASS_BASIC
COMMAND_CLASS_NOTIFICATION_V5
COMMAND_CLASS_ASSOCIATION_V2
COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3
COMMAND_CLASS_ASSOCIATION_GRP_INFO_V2
COMMAND_CLASS_MARK
COMMAND_CLASS_BASIC
Endpoint 3 (I3):
Device Class:
ZWAVEPLUS_INFO_REPORT_ROLE_TYPE_SLAVE_ALWAYS_0N
GENERIC_TYPE_SENSOR_NOTIFICATION
SPECIFIC_TYPE_NOTIFICATION_SENSOR
Command Classes:
COMMAND_CLASS_ZWAVEPLUS_INFO_V2
COMMAND_CLASS_VERSION_V2
COMMAND_CLASS_SENSOR_BINARY_V1
COMMAND_CLASS_BASIC_V1
COMMAND_CLASS_NOTIFICATION_V5
COMMAND_CLASS_ASSOCIATION_V2
COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3
COMMAND_CLASS_ASSOCIATION_GRP_INFO_V2
COMMAND_CLASS_MARK
COMMAND_CLASS_BASIC_V1
Endpoint 4:
Device Class:
ZWAVEPLUS_INFO_REPORT_ROLE_TYPE_SLAVE_ALWAYS_0N
GENERIC_TYPE_SENSOR_MULTILEVEL
SPECIFIC_TYPE_ROUTING_SENSOR_MULTILEVEL
Command Classes:
COMMAND_CLASS_ZWAVEPLUS_INFO_V2
COMMAND_CLASS_VERSION_V2
COMMAND_CLASS_ASSOCIATION_V2
COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3
COMMAND_CLASS_ASSOCIATION_GRP_INFO_V2
COMMAND_CLASS_SENSOR_MULTILEVEL_V7
NOTE: The above list is valid for the product with a
temperature sensor connected to TS terminal. In case the
sensor is not connected then following command class isn’t
supported:
COMMAND_CLASS_SENSOR_MULTILEVEL_V7
NOTE: The product supports the following
COMMAND_CLASS_NOTIFICATION_V5 events:
- Smoke Alarm v2 – Smoke detected, unknown location
(0x02)
- CO Alarm v2 – Carbon Monoxide detected, unknown
location (0x02)
- CO
2
Alarm – Carbon Dioxide detected, unknown
location (0x02)
- Heat Alarm v2 – Overheat detected, unknown location
(0x02)
- Water Alarm v2 – Water Leak detected, unknown
location (0x02)
- Home Security – Motion Detection, unknown location
(0x08)
This product can be included and operated in any Z-Wave
network with other Z-Wave certified devices from any other
manufacturers. All constantly powered nodes in the same
network will act as repeaters regardless of the vendor in
order to increase reliability of the network.
Important disclaimer
Z-Wave wireless communication is inherently not always
100% reliable, and as such, this product should not be used
in situations in which life and/or valuables are solely
dependent on its function.
Warning!
Do not dispose of electrical appliances as unsorted
municipal waste, use separate collection facilities.
Contact your local government for information regarding
the collection systems available. If electrical appliances are
disposed of in landfills or dumps, hazardous substances
can leak into the groundwater and get into the food chain,
damaging your health and well-being. When replacing old
appliances with new once, the retailer is legally obligated to
take back your old appliance for disposal at least for free of
charge.
This user manual is subject to change and improvement
without notice.
NOTE: User manual is valid for module with SW version S5
(SW version is part of P/N)! Example:P/N: ZMNHADx
HxS5Px
Qubino
Goap d.o.o. Nova Gorica
Ulica Klementa Juga 007
5250 Solkan
Slovenia
E-mail: info@qubino.com
Tel: +386 5 335 95 00
Web: www.qubino.com
Date: 12.04.2016
Document: Qubino_Flush 1 relay PLUS
user manual_V1.4_eng
