Queclink EA00022 User Manual

QSZTRACEA00022UM0101
3
2. Product Overview
2.1. Product Appearance
Figure 1. EA00022 Appearance
2.2. Parts List
Table 4. EA00022 Series Parts List
Name
Description
EA00022
125.5mm*62.08mm*101.0mm
tracker
3. Interface Definition
The EA00022 harness have 24-pin interface connector. It contains the connections for power,
Speaker, headlight and so on. The sequence and description of the connector are shown in the
following figure:

Queclink EA00022 Specifications

General

Brand	Queclink
Model	EA00022
Category	Control Unit
Language	English
