Microphone User Guide
3. Installation
3.1. Interface Description
There are 2 wires on microphone, the description of the wires and sample connection
between microphone and GV300 are showed as follow:
Microphone Connection GV300
PIN No. Color Description ←→ PIN No. Color
1 Red MIC Positive ←→ 1 Gray
2 Golden MIC Negative ←→ 2 Gray/Black
3.2. Installation Example
Device Connection Sample
GVXXX Device
AM100
ACCEAM100UG001 - 6 -
