Quick MILL Professional 05000A - Description of Components

DESCRIPTION OF COMPONENTS
1) Coffee button 1 cup
2) Coffee button 2 cups
3) Hot water - wash button
4) Steam switch
5) Main switch with indicator
6) Red “alarm” light
7) Yellow “no water” light
8) Green “ready” light
9) Orange “heating” light
10) Selection knob to adjust water quantity
11) Steam spout
12) Electrical plug
13) Air/steam mixer
14) Spent coffee container
15) Brush
16) Drip tray
17) Drip tray grid
18) Filter
19) Water feeding pipe
20) Water tank
21) Lock
22) Front door
23) Coffee hopper
24) Hopper lid
25) Hopper locking lever
26) Selection knob to ad adjust grinding
27) Selection knob to adjust coffee quantity
28) Cotter pin guard
29) Upper tamper guard
30) Upper tamper cotter pin
31) Upper tamper
32) O-ring gasket
33) Upper tamper showerhead
34) Brewing cup
35) Lower tamper showerhead
36) Lower tamper
37) Protective casing
38) Lower tamper cotter pin
