Quick B3 Series User Manual

B3Series
EN
15
INSTALLATION AND USE MANUAL - QUICK B3 SERIES WATER Heater - REV001A
9 - Dimensions
15L 3.9 gal 20L 5.3 gal 25L 6.6 gal
A
405 (15 61/64) 500 (19 11/16) 605 (23 13/16)
B
316 (12” 7/16)
C
123 (4” 27/32)
D
59 (2” 21/64)
E
Ø 306 (12” 3/64)
F
304 ÷ 318 (11” 31/32 ÷ 12” 1/2)
G 320 (12” 19/32)
H
87 (3” 27/64)
I
259 (10” 13/64)
30L 7.9 gal 40L 10.5 gal
A
495 (19 31/64) 623 (24 13/32)
B
366 (14” 13/32)
C
158 (6” 7/32)
D
75 (2 61/64)
E
Ø 366 (14” 13/32)
F
304 ÷ 318 (11” 31/32 ÷ 12” 1/2)
G 320 (14” 3/16)
H
79 (3” 7/64)
I
325 (12” 51/64)
60L 15.8 gal 80L 21.1 gal
A 721 (28 3/8) 921 (36 1/2)
B 404 (15” 29/32)
C 204 (8” 1/32)
D 85 (3” 11/32)
E Ø 400 (15 3/4)
F 270 ÷ 285 (10” 5/8 ÷ 11” 7/32)
G 320 (12” 19/32)
H 204 (8” 1/32)
I 323 (12” 23/32)
