B3Series
EN
B3 40 12 S L
4
INSTALLATION AND USE MANUAL - QUICK B3 SERIES WATER Heater - REV001A
SERIES NAME
TANK
CAPACITY
(l)
HEAT
EXCHANGER
(IF INSTALLED)
ELECTRIC ELEMENT
VOLTAGE:
(L) 110 VAC
(1) 12 VDC
(-) 220 VAC
ELECTRIC
ELEMENT
POWER (W)
1 - Information about the product
QUICK
®
RESERVES THE RIGHT TO MODIFY THE TECHNICAL CHARACTERISTICS OF THE EQUIPMENT AND THE CONTENTS OF
THIS MANUAL WITHOUT PRIOR NOTICE. IN CASE OF DISCORDANCE OR ERRORS IN TRANSLATION BETWEEN THE TRANSLATED
VERSION AND THE ORIGINAL TEXT IN THE ITALIAN LANGUAGE, REFERENCE WILL BE MADE TO THE ITALIAN TEXT.
NAUTIC WATER HEATER
Our long experience in the nautical sector has enabled us to develop a series of water heaters with innovative
features compared to the market standard. The advantages that Quick
®
nautic water heaters offer are:
• High-quality materials ensuring durability and resistance over time.
• Heat exchanger with a large exchanging surface.
• Possibility of producing hot water even with the electric element, complete with adjustable and safety thermostat.
• Relief/non-return valve that allows the water heater to drain the water when not in use.
• Easy installation on a at area.
1.0 - Model code
MODELS B3 15 B3 20
TANK
CAPACITY
Litres
15 20
US gallon 3.96 5.28
Tank material AISI 316 AISI 316
Thermal insulation material Polyurethane foam Polyurethane foam
External cladding material COMPOSITE COMPOSITE
Tank pressure during testing 800 kPa
(1)
800 kPa
(1)
Maximum working pressure 600 kPa
(1)
600 kPa
(1)
Electric element
voltage rating
12 VDC 220 VAC 110 VAC
110 VAC
220 VAC
12 VDC 220 VAC 110 VAC
110 VAC
220 VAC
Electric element power rating 300 W 500 W 600 W 1200 W 300 W 500 W 600 W 1200 W
Fittings diameter 1/2” 1/2”
Weight
(2)
Kg 7 8,1
Lb 15.4 17.8
(1) 1 Bar = 100 kPa • (2) with equipment vacuum
12V 110/220V
Functional temperature 60°C adjustable 40°C - 80°C
Safety temperature 90°C 87°C
