BOW THRUSTER BTQ140 - BTQ185 IT GB - REV002C
MAINTENANCE
WARNING: make sure that the power supply to the
electric motor is not switched on when maintenance
operations are carried out.
Quick
®
Bow Thrusters are made in materials that are resist-
ant to the sea environment: In any case, it is indispensable
to periodically remove salt deposits that form on the outer
surfaces to avoid corrosions and consequent system inef-
ficiency.
Dismantle once a year, following the points below:
• Keep the propeller (11) and the gearleg (9) clean.
• Paint the propeller and the gearleg with anti-vegetative
paint before each season.
WARNING
: do not paint the zinc anode (13), the seal-
ings and the propeller shaft Be careful not to allow
paint to penetrate in the “tracks” of the gearleg (9) in
which the propeller hub moves.
• Check the zinc anode (13) frequently.
• Replace the zinc anode before every season or when it is
more than half consumed.
• After any maintenance, make sure that the bolts (16) that
lock the flange (6) to the gearleg (9) are well tightened.
• After every maintenance, make sure that the propeller
(11) is well tightened and that the bolts (1) locking the
electric motor (3) are tight.
• Make sure that all electrical connections are clean and
firmly fixed (23 and 24).
• Make sure that the batteries are in good condition.
POS.
DESCRIPTION CODE
1 Motor mounting screw
MBV1025MXCEO
2 Motor mounting washer
MBR10X000000
3A Motor 6KW 12V
EMFEL6012000
3B Motor 6KW 24V
EMFEL6024000
4 Even tension device
PVPR43000000
5 Half-joint
MMSGM1100000
6 Motor flange
SGMMEM185000
7 Gearbox gasket
PGRDEL185000
8 O-Ring
PGR031250000
9 Gearleg
MREM18500000
10 Propeller drive pin
MBSC05025A00
11 Propeller
PVEL18500000
12 Propeller mounting nut
MBD12MXET000
13 Anode tip
MMANBTQ18500
14 Anode tip mounting screw
MBV0625MXCE0
15 Washer
MBR08X000000
16 Gearleg mounting screw
MBV0850MXCE0
17A Reversing
contactor
unit
350A 12V
ERBTQ1235000
17B Reversing
contactor unit
350A 24V
ERBTQ2435000
18 Clamp reversing
contactor unit
MMSTBTQ15000
19 Grower Ø5
MBG05X000000
20 Screw M5
MBV0506MTCT0
21 Washer
MBR051510X00
22 Reversing
contactor unit
mounting screw
MBV0510MXCE0
23 Negative reversing
contactor
SAECCCBTQNG0
24 Command wire
SAECCCBTQCM0
25 Carter spacer B
MBTCB2600TMM
26 Carter reversing
contactor
unit
PCCCBTQA0000
27 Fasteners carter reversing
contactor
PBD04STPN000
