10
BOILER BX15-100 - REV004A
TECHNICAL DATA
GB
HOW TO IDENTIFY THE WATER HEATER THROUGH THE CODE:
a b c d e
a
a
a
a
a
a b c d e
a
a
a
a
a
1° EXAMPLE : BX2005S 2° EXAMPLE : BX8012SL
BX 80 12 S LBX 20 05 S -
Product
Name:
[ BX ] = “Boiler Inox”
Tank capacity
(liter):
[ 15 ] = 15 liter
[ 20 ] = 20 liter
[ 25 ] = 25 liter
[ 30 ] = 30 liter
[ 40 ] = 40 liter
[ 50 ] = 50 liter
[ 60 ] = 60 liter
[ 80 ] = 80 liter
[ 100 ] = 100 liter
Power of electric
element:
[ 00 ] = not installed
[ 05 ] = 500 W
[ 06 ] = 600 W
(4)
[ 12 ] = 1200 W
Heat
exchanger:
[ S ] = present
a
b c d
Voltage of electric
element (if installed):
[ - ] = 220 Vac
[ L ] = 110 vac
e
(1)
1 Bar = 100 kPa
(2)
Available on request
(3)
Of empty equipment
(4)
Only for 110 Vac
MODELS
BX 15 BX 20 BX 25 BX 30 BX 40 BX 50 BX 60 BX 80 BX 100
TANK CAPACITY
Liters
15 20 25 30 40 50 60 80 100
US gallon 3.96 5.28 6.6 7.92 10.56 13.2 15.85 21.13 26.4
Tank material AISI 316 Stainless steel
Thermal insulator Polyurethane foam
External cladding material AISI 304 Stainless steel
Tank pressure during testing 800 kPa
(1)
Maximum working pressure 600 kPa
(1)
Electric element voltage rating
(2)
220 Vac ± 10% - (110 Vac ± 10%)
Electric element power
(2)
500 W [Model 05] - 600 W [Model 06]
(4)
- 1200 W [Model 12]
Outputs diameter 1/2”
Weight
(3)
Kg 9,5 10,9 12,3 12,6 14,7 17,0 19,0 22,7 26,4
Pounds 20.9 24.0 27.1 26.5 31.1 36.2 40.6 48.7 58.2
Quick
®
reserves the right to introduce changes to the equipment and the contents of this manual without prior notice.
In case of discordance or errors in translation between the translated version and the original text in the Italian language, reference will be made to the Italian or English text.
