Quick F 1012 D User Manual

AFR 700/1000/1400W - REV009B
IT
44
MAIN CONNECTION DIAGRAM
QUICK
®
WINDLASS
WATERTIGHT HAND
HELD
CHAIN-COUNTER
MOD. CHC 1102 M
MULTI-PURPOSE
WATERTIGH
HAND HELD
REMOTE
CONTROL
MOD. HRC 1002
RADIO RECEIVER
MOD. 1302 (2CH)
WATERTIGHT PANEL
CHAIN-COUNTER
MOD. CHC 1202 M
WINDLASSES
CONTROL BOARD
MOD. 800
L = L1 + L2 + L3 + L4
SENSOR
MOTOR
FUSE
4A (12V) 2A (24V)
BATTERY
HYDRAULIC
MAGNETIC
CIRCUIT BREAKER
(see table on page
4/12/20/28/36)
C
A2
A1
CONTACTOR UNITS
MOD. T6315-12 (12V) MOD. T6315-24 (24V)
L1
L2
L3
BLUE
BROWN
BLACK
BLUE
BROWN
BLACK
UP
SENSOR
DOWN
-
+
GREY
RED
GREEN
BROWN
WHITE
BLUE
BLACK
BLUE
BROWN
BLACK
L3
150
CAN H
CAN L
CAN H
CAN L
CAN L
CAN H
L4
MOD. 900/D
DOWN
FOOT SWITCH
MOD. 900/U
UP
UP
DOWN
-
+
