16
GB
GP2 SERIES GENIUS 1500/2000 - REV000A
-
+
M1 M2
MULTI-PURPOSE
WATERTIGHT HAND HELD
REMOTE CONTROL
MOD. HRC 1002
WINDLASS
BATTERY
HYDRAULIC-
MAGNETIC CIRCUIT
BREAKER
(SEE TABLE ON
PAGE 14)
REVERSING
CONTACTOR UNIT
MOD. T6415-12 (12V)
MOD. T6415-24 (24V)
C A2
FOOT SWITCHES MOD. 900U AND 900D
BLACK
BROWN
BLUE
BROWN
BLACK
BLUE
A1
FUSE
4A (12V)
2A (24V)
BASIC SYSTEM
WATERTIGHT
PANEL
CHAIN COUNTER
WINDLASSES
CONTROL
BOARD
WATERTIGHT HAND HELD
CHAIN COUNTER
QUICK
®
ACCESSORIES
FOR WINDLASS OPERATION
REMOTE RADIO CONTROLS
L3L2
L1
L4
L5
L = L1 + L2 + L3 + L4 + L5
CONNECTION DIAGRAM
POCKET
RECEIVERS TRANSMITTERS
HANDHELD
