Quick PRINCE DP2E Series User Manual

DP2E 600/1000/1100 - REV000A
34
MAIN CONNECTION DIAGRAM
QUICK
®
WINDLASS
WATERTIGHT HAND HELD
CHAIN-COUNTER
MOD. CHC1102 M
MULTI-PURPOSE
WATERTIGH HAND
HELD
REMOTE
CONTROL
MOD.HRC1002
WATERTIGHT PANEL
CHAIN-COUNTER
MOD. CHC1202 M
WINDLASSES
CONTROL BOARD
MOD. 800
MOD. 900/D
DOWN
FOOT SWITCH
MOD. 900/U
UP
L = L1 + L2 + L3 + L4 + L5
SENSOR
MOTOR
FUSE
4A (12V) 2A (24V)
BATTERY
HYDRAULIC
MAGNETIC
CIRCUIT BREAKER
(see table on page
4/10/16/22/28)
C
A2
A1
REVERSING CONTACTOR UNITS MOD. T6415-12 (12V) MOD. T6415-24 (24V)
L2
L1
L4
L5
BLUE
BROWN
BLACK
BLUE
BROWN
BLACK
UP
SENSOR
DOWN
-
+
CAN H
CAN L
GREY
RED
GREEN
BROWN
WHITE
BLUE
BLACK
BLUE
BROWN
BLACK
L3
150
CAN H
CAN L
CAN H
CAN L
-
UP
DOWN
+
-
RADIO RECEIVER RRC MOD. R02 (2CH)
