19
EN
RRC R02/12 - REV003A
MAINTENANCE - TECHNICAL DATA
MODELS R02 R04 R06 R08 R10 R12
INPUT CHARACTERISTICS
Power supply 10,5 ÷ 31 Vdc
Quiescent current 25 mA
Absorption with 2 relays activated 120 mA
OUTPUT CHARACTERISTICS
Relay number 2 4 6 8 10 12
Relay contact rating* 15A
CHARACTERISTICS OF THE RECEIVER
Frequency 434.420 Mhz
Modulation FSK
Number of transmitters that
can be stored
50
Compliant with directive 2014/53/EU (RED)
GENERAL CHARACTERISTICS
Operating temperature from -15°C to +70°C
Dimensions (W x H x D) 143 x 141,7 x 61,4 mm
Weight (with all relays installed) 300 g 370 g
MAINTENANCE
The RRC radio receiver does not require particular maintenance. In order to ensure optimal operation of the re-
mote control, once a year verify cables and electrical connections.
TECHNICAL DATA
QUICK
®
RESERVES THE RIGHT TO MODIFY THE TECHNICAL CHARACTERISTICS OF THE EQUIPMENT AND THE CONTENTS OF THIS MANUAL WITHOUT PRIOR NOTICE.
* With two enabled relay, having a load of 15A each (30A total), the nominal operating time is 17 seconds and the idle time is 16 minutes.
With one enabled relay, having a load of 15A, the nominal operating time is 10 minutes and the idle time is 10 minutes.
