MAINTENANCE
The battery charger does not need any maintenance. To ensure optimum performance from the equipment,
once a year check the cables and the electrical connections.
MODEL SBC 300 ADV PLUS FR SCB 500 ADV PLUS FR SBC 700 ADV PLUS FR SBC 650 ADV PLUS FR
OUTPUT CHARACTERISTICS
Maximum output current
(1)
30 A 40 A 60 A 30 A
Charge absorption voltage 14,1 Vdc (14,4 Vdc GEL)
28,2 Vdc (28,8 Vdc GEL)
Charge float voltage 13,5 Vdc (13,8 Vdc GEL) 27,0 Vdc (27,6 Vdc GEL)
Residual ripple
(2)
30mV RMS max
Charging characteristics Automatic in three stages IU
o
U
Number of outputs
(3)
3
INPUT CHARACTERISTICS
Supply voltage 280÷83 Vac, with power reduction under 97 Vac
Frequency 45÷66 Hz
Maximum absorption
(230/240 Vac)
(4)
2,5 A 3,3 A 4,8 A 4,5 A
Maximum absorption (115 Vac)
(5)
5,1 A 6,8 A 9,8 A 9,5 A
Power factor (cos
ϕ
)1
PROTECTION
Reverse polarity
(6)
Yes, through fuse
Overload Yes
Output short circuit Yes
Overvoltage in output
(7)
Yes
Overheating Yes
Battery overtemperature Yes, optional
AMBIENT CHARACTERISTICS
Operating temperature -20 ÷ +70 °C, with power reduction over +50 °C
Cooling Forced, by variable speed cooling fan
Humidity Max. 95% RV without condensation
CASE
Material Stainless steel - Cycoloy
®
Colour Polished steel - OR5066
Dimensions (WxHxD) 272 x 334 x 127 mm 272 x 412 x 127 mm
Weight 4,2 kg 5,4 kg
GENERAL
CAN bus interface Yes
Safety classification EN 60335-2-29
EMC class EN 55022/B EN 55022/A
