MAINTENANCE - TECHNICAL DATA
GB
QUICK™ RESERVES THE RIGHT TO INTRODUCE CHANGES TO THE EQUIPMENT AND THE CONTENTS OF THIS MANUAL WITHOUT PRIOR NOTICE.
MAINTENANCE
The voltage reducer does not need any maintenance.
To ensure optimum performance from the equipment once a year check the cables and the
electrical connections.
MODEL VRS 10 VRS 16 VRS 23
OUTPUT CHARACTERISTICS
Maximum output current
(1)
Maximum output load
(2)
Rated output voltage
Output voltage stability
Residual fluctuation
8 A 12 A 18 A
10 A 16 A 23 A
13,5 Vdc ± 0,5Vcc
1%
30mV rms
20 ÷ 30 Vdc
8,3 A 11,9 A 17,8 A
Natural
Max. 95% RV, without condensation
85%
ECE/ONU N.10/02 (DIRECTIVE 95/54 CE)
Aluminium
160 x 75 x 35 170 x 105 x 35 200 x 116 x 41
390 g 550 g 780 g
INPUT CHARACTERISTICS
Power supply voltage
Maximum absorption
CASE
Material
Dimensions (WxHxD)
Weight
Yes
(3)
Yes
(4)
Yes
(5)
PROTECTION
Reverse output polarity
Output short circuit
Output overvoltage
AMBIENT CHARACTERISTICS
Cooling
Humidity
GENERAL
Efficiency rate
EMC Class
(1)
For continuous operation.
(2)
For intermittent operation (1 min ON, 1 min OFF at an ambient temperature of 20 °C).
(3)
Through diode.
(4)
Through fuse.
(5)
Through zener diode.
TECHNICAL DATA
