AUTO BATTERY TESTER
19
USER’S MANUAL
3.4 Additional Functions:
3.4.1 Language Choice.
If the machine has a multi-language version, go to the menu 2 and select
the language you use appropriate language, choose YES and press enter to
confirm it, so you can use the language version of the machine; or Use Scroll
button to look throug h next language till the suitable one. Once confirm the
language, press enter again, then exit it.
MENU: 2.
LANGAUGE
English?
Yes No
3.3.4 24V system testing.
It should not be tested on 24V directly. It will cause damage the unit. For
12V x 2 batteries (in series or parallel), disconnect the connections and test
them individually.
The battery in parallel must be disconnected from the negative connection,
and then tested on a single battery. If you do not cut off the negative
connection, will lead to erroneous battery test results.
