Part Code
QSVMI-18A
1 Wall-Mounting Frame 01252004 1
2 Rear Case 22202329 1
3 Fan Bearing 76512203 1
4 Screw Cover 24252015 3
5 Swing Louverb 105120472 11
5 Swing Louver 10512430 1
6 Swing Link 1 10582057 1
7 Swing Link 2 10582058 1
8 Water Tray 20182057 1
9 Guide Louver
（
up
）
10512085 1
10 Guide Louver
（
down
）
10512086 1
11 Cross Flow Fan 10352022 1
12 Evaporator Assy 01002913 1
13 Drainage Pipe 05230014 1
14 Evaporator Support 24212067 1
15 Filter 11122048 2
16 Front Case 200026524 1
17 Front Panel 2000284402 1
18 Remote Controller YT1F 30510049 1
19 Displaying Light Board 22432071 1
20 Electric Box Cover 1 20112019 1
21 Wire Clamp 71010103 1
22 Terminal Board (3
位
) 4201026601 1
23 Electric Box Cover 20112020 1
24 Main PCB 30038022 1
25 Transformer 57X25F 43110257 1
26 Room Sensor 15k 390001912 1
3900019814 1
3900019815 1
3900019816 1
28 Sensor Insert 42020063 3
29 Electric Box 20112018 1
30 Lower Shield of Electric Box 01592037 1
31 Upper Shield of Electric Box 01592038 1
32 Stepping Motor MP35XX 15213001 1
33 Motor Clamp 26112095 1
34 Helicoid tongue 26252009 1
35 Motor FN20K-PG 15012718 1
36 Pipe Clamp 24242001 1
37 Connecting Cable / 1
38 Plank Cable 4003004201 1
39 Jumping Connector 4202300106 1
No Description Qty
27 Tube Sensor 20k
Components and Parts List 3
The above data are subject to be changed without notice.
