5
10 Bumper Bar
Insert bumper bar into
openings on seat until you hear
each side click (Figure 10).
To Remove
Bumper Bar
Press buttons under each side
of bumper bar and pull the bar
off the seat (Figure 10a).
IMPORTANT: Always secure
the child with the restraining
straps.
11 Footrest
To adjust the footrest up, pull
footrest up. To adjust down,
press the buttons on both sides
and push down (Figure 11).
12 Swivel Wheel
Lock the swivel wheel when using
the stroller in a straight direction
for a long period. To lock, push
the lock lever downward and
rotate wheel until it locks into
place (Figure 12). To unlock,
push the lock lever upward.
10
10a
11
12
13 To Use Restraint
System
Unbuckle restraint system
(Figure 13). Place your child
in the stroller, with the crotch
strap between the child’s legs.
Fit clips together. Slide clips into
buckle until you hear a “click”.
To tighten strap, pull strap end
down (Figure 13a).
To loosen strap, back strap
back through loops (Figure
13b).
Adjust straps snugly around
your child (Figure 13a).
WARNING
• NEVER LEAVE CHILD UNATTENDED. ALWAYS keep
child in view when in stroller.
• AVOID SERIOUS INJURY from falling or sliding out.
ALWAYS use seat belt. Check frequently to make sure it is
secure. Belts must be threaded exactly as shown (Fig. 14b).
• Failure to follow these instructions could result in the
serious injury or death of your child.
13
13a
13b
14 Adjust Restraint Height
The shoulder straps have
three height positions for
your growing child. Unsnap
shoulder cushions from harness.
Unthread shoulder straps
(Figure 14). Push shoulder
straps through back of the seat
pad into the desired slot (Figure
14a). Thread straps as shown
(Figure 14b). Attach snaps.
14a
14
14b
