1. Check that the sensor is level
from side to side and pointed at the
area you desire. If unit is tilted, part
of the detection zone may be high
in the air over people’s heads.
Solution: Position sensor exactly
level from side to side.
2. Check that the sensor is not
mounted too high. If mounted
above 20 feet, much of the usable
range will be lost.
Solution: Mounting at 6 feet to
12 feet allows maximum range.
3. Check that movement is not
directly towards sensor. Sensor
will see movement across its
pattern more quickly. To fix,
move the sensor.
4. Check that movement far away
and directly towards sensor is not
entirely within one zone.
Problem:
Sensor will not detect until
movement crosses zones
Solution:
“Micro Adjust” sensor by moving
sideways 1/4". This may move the
zones to
Technical Tips:
Range Appears Limited
50'
40'
20'
6-12'
Less
Sensitive
More
Sensitive
10
WRONG!
OK!
No Detection Until Here
Detection Much Sooner
