Rac HP214 - Page 3

COMPONENTS
Component List
1. Detergent container
2. Water supply inlet
3. ON/OFF switch
4. High pressure outlet
5. Trigger gun
6. High pressure hose
7. Rotary brush
8. Fixed brush
9. Lance extension
10a. Lance rest
10b. Lance holder
11. Adjustable lance
12. Cleaning needle
13. Compact patio cleaner
14. Quick connector (Female)
15. Quick connector (Male)
16. Cable holder
17. Turbo lance
Technical specication
Rated voltage:
Rated power:
Protection class:
Degree of protection:
Permissible pressure:
Rated pressure:
Inlet pressure:
220-240VAC ~ 50Hz
2000W
I
IPX5
16.5 Mpa / 165 Bar
11.0 Mpa / 110 Bar
1.5 - 4 Bar
Supply water temperature:
Nozzle spray angle:
Max output ow rate:
Net weight (machine only):
Cable length:
Hose length:
Noise value:
Noise value:
0-50°C
0 – 90 degree
6.0L/min
13.2Kg
5m
6m
89 db Lwa
84 db Lpa
-2-
1
3
2
4
6
13
10a
10b
16
17
5
7
9
8
14
12
11
15
