2x6mm screw
..........4
....2
...2
CA
5/32” (4mm)
Wing bolt flat
Wing bolt flat 1/8”(3mm)plywood
Wing bolt flat
Center line
Using the wing bolt flat as a
template, trace around the outside
edge of the wing bolt flat and then remove it.
Using a sharp hobby knife, cut away the covering inside the lines. Not
to cut into the wood.
Apply the wing bolt flat in place and secure it with CA glue.
11- Wing bolt flat /
Verstarkung
Bottom view /Ansicht von unten
CA
Cut away only the
covering
4mm collar
10- Fixed gear / Starres Fahrwerk
ABS Wheel well cover
CA
Bottom view /Ansicht von unten
9- Fixed gear / Starres Fahrwerk
