Radio Shack B/W 1/3-INCH BASIC CCD CAMERA - Page 5

5
TYPICAL CONNECTIONS OVERVIEW
Supplied Cable
Camera
TV/Monitor
AC Adapter
Video (Yellow)
DC12V Jack
Audio (White)
A/V Input Jacks
DC12V Jack
9-Inch Security Monitor Cat. No. 49-2511
Mini-DIN Jack
Cable Supplied
with Cat. No. 49-2511
Video (Yellow)
Audio (White)
Supplied Cable
Camera
