Note
: Normally, the direct-to-home receiver supplies power to both the antenna amplifier and
the LNB converter.
Installation C
SAT
Dish
DC Passed
To LNB
In-Line
To ANT
Satellite Signal
Splitter Co mbiner
AMP
Section, 50-2200 MHz
DC 13V/17V From
Sat-Receiver
(15-1170)
ANT
SAT
TV SET
TO TV
ANT
LNB
IN
TV/Sat Dip lexer
Amplifier
