Remote control overview
2
POCKET is powered by 2x 3.7V 18650 Lithium Ion cells and is charged using the built-in USB-C port. The
charging circuitry is designed for charging 2x 3.7V Lithium Ion batteries only. The nominal voltage is 3.7V and
the maximum charging voltage is 4.2V.
Never charge 3.6V LiFe and 3.6V 18650 Lithium Ion packs with the onboard charger. Charging or using the
wrong battery chemistry/polarity may cause permanent damage to the PCB and in certain situations cause
fires.
Check the voltage and condition of the battery regularly and never charge the device unattended. Only charge
in safe areas away from combustable materials. Refrain from charging the radio unit if it was exposed to water
or was damaged in any way. RadioMaster does not assume any responsibility for any adverse consequences
caused by the use or misuse of this product.
External Module Bay
S1-Pot
Stick storage compartment
SE-Momentary switch
TYPE-C Charge Port
SD Card Slot
3.5mm
Headphone Jack
USB Port
DSC Trainer Port
Power Button
Left Gimbal
SYS Button
PAGE< Button
PAGE> Button
RTN Button
LCD Screen
Trim Switchs
SA-Self locking switch SD-Self locking switch
Right Gimbal
Speaker
Lanyard Loop
Antenna
MDL Button
TELE Button
Menu Wheel
SB-Position
SC-Position
Power Requirements.
