Raider RD-LM36 - Spare Parts List

55
Number Part NameDescription Unit Quantity
1.01 bottom shell pcs 1
1.02 uppercover pcs 1
1.03 transportation handle pcs 1
1.04 spring65Mn pcs 1
1.05 back cover PP pcs 1
1.06 deflector platePP pcs 1
2.01 switch pcs 1
2.02 lower handle bar pcs 1
2.03 bolt rectangular neck, M6x45 pcs 2
2.04 flatwahser φφ6x 18x1.2 pcs 2
2.05 lock button pcs 2
2.06 NutM6, anti-loosen, inside of lock button pcs 2
2.07 cord clip pcs 3
3.01 handle for grass catcher pcs 1
3.02 baffle plate pcs 1
3.03 cover of grass catcher pcs 1
3.04 grass catcherbag pcs 1
4.01 wheel cover for wheelmφ130m pcs 4
4.02 washer inner lock tooth pcs 4
4.03 wheelφ130mm pcs 4
4.04 spring steel pcs 4
4.05 shaft for back wheel steel pcs 1
4.06 shaft for front wheel steel pcs 1
5.01 motor pcs 1
5.02 orientation jacket pcs 1
5.03 blade pcs 1
5.04 flatwahser φφ8x 16x1 pcs 1
5.05 spring washer φ8 pcs 1
5.06 bolt outer hex, M8x1.25x30 pcs 1
6.01 screw ST4x16, sharp end pcs 2
6.02 Screw ST4x16, flat end pcs 9
6.03 screw ST5x18, flange pcs 4
SPARE PARTS LIST
