Circular selector
When the dial is set to the AUTO position,
the programs are set to run automatically
When the dial is pointing to the SET
position, the current time and date can be
modifi ed.
zone
Independent program per station
B
Programming button
The button increases values
The button confi rms values and continues
the programming (ENTER)
The button decreases values
C
Terminal compartment
24 vac Cables transformer Input
sensor Rain sensor input
M
Pump control or master valve Output
1...10
Sector output
16
The button CLEAR eliminates programming
17
Protection fuse 1.0 A
18
RESET button restarts the controller
D
Extra bottons
MANUAL allows for watering manually
without disturbing preset programs.
EXTRA It allows you to personalize the start
of pump and sensor
BUDGET Adjustments can be made to
watering using percentages
E
Backlight Screen
1 The rain sensor is active
2 Backup batteries are low
3 Delay to start time is active
4 Fertilizer Output up to 90% with 10%
increment
5 Indicates the next start time
6 Indicates the start time
7 Indicates the programs
8 Indicates watering in progress
9 Indicates that the seasonal adjustment
(budget) is active.
10 Hours
11 Day
12 Indicates the irrigation time
13 Days of the week
14 indicates the interval between cycles
15 Indicates manual watering in progress
