Impulse load 80 Watts 80 Watts 80 Watts
Rated power 60 Watts 60 Watts 60 Watts
Minimum amp power 30 Watts 30 Watts 30 Watts
Efficiency 90 dB 1W/1m 90 dB 1W/1m 90 dB 1W/1m
Frequency response 65 – 30,000 Hz 65 – 30,000 Hz 65 – 30,000 Hz
Impedance 4 4 4
Slope 2x 12 dB / octaves 2x 12 dB / octaves 2x 12 dB / octaves
Crossover frequency 180 / 4,500 Hz 180 / 4,500 Hz 180 / 4,500 Hz
Thermal protection PTC PTC PTC
Installation depth without
/ with ring
36 / 27 mm 36 / 25 mm 36 / 25 mm
Outer diameter without /
with mounting clips
100 / 138 mm 100 / 138 mm 100 / 138 mm
Outer diameter with ears
without / with ring
119 / 138 mm 119 / 138 mm 119 / 138 mm
Installation diameter 103 mm 103 mm 103 mm
Pitch circle diameter 138 mm 138 mm 138 mm
Installation depth 11 mm 11 mm 11 mm
Outer diameter 44 mm 44 mm 44 mm
Installation diameter 44 mm 44 mm 44 mm
Operating and installation tips
Vehicle-specific Rainbow systems are high-quality car hi-fi systems, which can be operated with any
commercially available amplifier. We recommend using a power amplifier with at least 30 watts for the
sensible utilization of an optimal sound reproduction in the vehicle. The excellent efficiency of Rainbow
speakers enables an enormous dynamic range, which is already fully achieved at a minimum output.
Coordinating with the vehicle as well as the use of selected components in the switches are trendsetting
design details of our systems.
Approaches to sound optimization are the lining of the woofer volume with insulating material and the
sound-damping of the door panels with damping mats on the inside of the door.
Note:
The high power speaker outputs of standard car radios are achieved with high power wattage. The
performance data is usually pure marketing figures. Our loudspeaker units are highly efficient and can
also be used directly with the Intelligence Line, also directly on the car radio with at least 2x12 watts
RMS. However, we generally recommend the use of an amplifier in order to take advantage of the full
dynamic range of your speakers.
