RainSoft EC4 50 V - Control Parts List

21
Item Quantity Part Number Description
1 1 17487 Rear housing
2 1 17501 Brine cam gear
3 1 17492 Brine cam gear bracket
4 1 17537 Valve motor w/computer cam 24v 50/60 hz
5A 2 17526 Switch 45 deg actuator gold contact (indoor)
5B 2 19536 Sealed switch C-NC male connector red (outdoor)
5C 2 19537 Sealed switch C-NO female connector brown (outdoor)
6 2 17548 10-32 x 1.50 screw pan h phil ss
7 2 18135 4 x 1.25 screw slotted hex washer type 25
8 5 17542 4-20 x .375 screw pan h phil ss
9 1 17853 Front door housing gold
10 1 17855 Front housing gold
11 11 19701 EC4 computer assembly
12 2 17542 4-20 x .375 screw pan h phil ss
13 1 17490 Rear housing cover
14 1 19693 EC4 PCB computer wire harness
