ENGLISH RAISmanualforRais600&Rais80
Rais600 Rais80
Nominaloutput(kW): 5 5
Min./Max.outp ut(kW): 26 26
Heatingarea(m
2
): Ca.80 Ca.80
Size,widt h/depth/height(mm): 700  448  475 504  408  960
Combustionchamberwidth/depth/height(mm). 530  330  350 372  238  300
Recommendedamountofwoodwhenfuelling(kg)
(Basedon2  3logsofwoodapprox.25cm)
1.6 1.7
Min.uptake/Min.draught(Pascal): 12 11
Weight(kg):  91 115
Smokegasmassflow(g/s): 5.6 5.99
Smokegastemperature(°C): 302 259
Intermittentoperation: Fuellingshouldbeundertaken
within3hours
Efficiency(%): 75 75
ParticlesafterNS3058/3059(g/kg): 5.7 5.7
DustmeasuredaccordingtoDin+(mg/Nm
3
):
PleaseNote,thisappliancehasbeentestedbythemanufacturersandworksona
3mstraightflue.
