RAIS Q-TEE - RAIS Q-TEE Model Specifications

August 2013
ENGLISH RAIS - manual for Rais Q-Tee
5
Q-Tee 57
Nominal output (kW): 4.7 Min. / Max. output (kW): 4 - 5 Heating area (m
2
): Ca. 30-90
Size, width/depth/height (mm): 425 / 372 / 570 Combustion chamber width/depth/height (mm). 317 / 270 / 270 Recommended amount of wood when fuelling (kg) (Based on 2 - 3 logs of wood approx. 25cm)
1.5
Min. uptake / Min. draught (Pascal): -12 Weight (kg): ( Steel Door / Glass Door ) 79 / 81 Smoke gas mass flow (g/s): 3.7 Smoke gas temperature (°C): 283 Intermittent operation: Fuelling should
be undertaken
within 3 hours
Efficiency ( % ) 73 Particles after NS3058/3059 (g/kg) 3.6 Dust measured according to Din+ (mg/Nm
3
) 20
Q-Tee 65
4.7
4 - 5
Ca. 30-90
425 / 372 / 650 317 / 270 / 270
1.5
-12
82 / 84
73
3.6
20
3.7
283
Fuelling should
be undertaken
within 3 hours
Q-Tee 85
4.7
4 - 5
Ca. 30-90
425 / 372 / 850 317 / 270 / 270
1.5
-12
94 / 96
73
3.6
20
3.7
283
Fuelling should
be undertaken
within 3 hours
Specifications
Please Note, this appliance has been tested by the manufacturers and works on a 3m straight flue.
