2 Product specifications
Feature
Specifications
Form factor
Mini PCI express
Baseband processor Semtech SX1302
emulates 8x 8 channel LoRa packet detectors
8x SF5-SF12 LoRa demodulators, 8x SF5-SF10 LoRa demodulators
Rx sensitivity down to -139dBm@SF12, BW 125 kHz.
LoRa feature
Supports global license-free frequency band (EU868, CN470, US915, AS923, AU915,
KR920, IN865)*
Listen Before Talk (optional)
Fine Time Stamp (optional)
Frequency**
EU433/CN470/EU868/US915/AS923/AU915/IN865/KR920
Power supply
3.3v
Compatibility
RJ45 (10/100 Mbps)
LoRa:
GPS:
Antenna
*Supported bands depends of the model.
3 Interfaces
