OIM‐600056 Rev.0 17
On a monthly basis, pump a quality bearing grease (8 to 10
pumps) through each grease zerks.Routinely pumping grease
into the bushings acts to replenish the lubricant as well as flush
out any contaminants.Depending on the amount of usage and
the environment, this process
may need to be repeated during
theoperationcycle.
Ram recommends using Shell Gadus V220 2 Grease. Or other
extremepressureandanti‐wearlithiumgrease.
5.8. DiscBrake
The automatic disc brake does not require any routine
adjustment.However,atleastannually,thediscbrakeshouldbe
subjectedtoloadtest.Thediscbrakeshouldsafelyarresta125%
SWL.Ifthe disc brake allowsanyslippage, the disc brake should
bedisassembled,inspected,andrepaired.
Also,duringoperation,
thediscbrakefeelswarmtothetouch,ifa
brake chattering noise can be heard, or the winch performance
(linepullorspeed)isreduced,thebrakemaybedragging.Ifany
of these symptoms are present the disc brake should be
disassembled,inspected,andrepaired.
5.9. AutoDrumBrake
The automatic drum is actuated by a pneumatic cylinder.This
cylinder contains a compression spring that applies (retracts the
rod) the brake band and air pressure delivered to the cylinder
releasesbrake(extendstherod).Theairlinetothebrakecylinder
is plumbed with in via a quick exhaust valve.
This valve quickly
exhausts the air cylinder and allows the brake to set quickly.
Routinely inspect the quick exhaust valve to ensure that it is
working properly and that the exhaust port does not become
restrictedtherebycausingthebrakestosetslowly.
As the brake contacts directly on the
brake surface of the winch
drum it is susceptible to contaminants such as rust, dirt and oils
thatmaygetonthebrakingsurfaceandbecomeimbeddedinthe
friction lining of the brake bands.The brake linings and brake
surfaceshouldbeinspectedandcleanedroutinely.
As this is a
friction based brake, the friction lining needs to
inspected regularly for excessive wear.If any portion of the
frictionliningmeasures1/16”thickorless,thebrakebandsneed
tobere‐lined orreplaced.As the friction liningwears,thebrake
linkage will need to be tightened so as
to maintain its ability to
holdthe rated load.The band brake should safely arrest a 125%
SWL.
Ifthebrakecannotbeadjustedtoholdtheload,thebands need
tobereplacedorre‐lined.
Never attempt to service or repair any portion of the brake
systemwith
asuspendedloadortensiononthewirerope.
Loadtestingisrequiredafterreplacinganycomponentofthe
brakesystem
5.10. RoutineInspectionandMaintenanceReport
This equipment should be routinely inspected and records kept
for each maintenance event and inspe ction interval.Proper and
detailed inspection records provide a historical basis for
continuingevaluationof the service of theequipment.Basedon
the conditions under which the equipment is used, the schedule
of maintenance and inspection can
be adjusted accordingly.
Reports should be signed and dated by the person who
performedtheinspectionandkeptonfilewheretheyarereadily
availableforreview.AMaintenanceIntervalChartisincludedon
thefollowingpage.
5.11. DailyInspectionChecklist
This equipment should be cleaned, inspected, and maintained
priortoeachshiftorpriortoeachtimetheequipmentisputinto
use.A Checklist had been provided (page 19) that can be used
dailyoratthestartofeachshiftto verify system readiness.This
checklist does not substitute
for routine maintenance and
thoroughinspectionsscheduleperiodicallybasedonenvironment
andusage.
