SECTION A-A
SCALE .08
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
125
SURFACE
FINISH:
SURFACE FEATURES: MACHINED PARTS ONLY
T.I.R
.005 PERPENDICULAR .015
FLATNESS .010 PARALLEL
.015
SEE NOTE
X.X ±0.03
X.XX ±0.015
X.XXX ±0.005
FRACTION ± 1/16
ON ALL
MACHINED
SURFACES
DIMENSIONS:
BREAK ALL SHARP EDGES
UNLESS OTHERWISE SPECIFIED:
ALL DIMENSIONS ARE IN INCHES
AND ALL TOLERANCES ARE AS STATED
3rd ANGLE PROJECTION
DO NOT SCALE
R7PT
LBS.
-
EST. FINISHED
WEIGHT
ORIGINAL JOB NO.
MODEL NUMBERNEXT ASSEMBLY
ANGLES: ±
0.5°
APVD:
M. WEHMEYER
M. TROYER
M. TROYER
1/22/2019
1/21/2019
CKD:
M. WEHMEYER
DWN:
ENG:
1/22/2019
TITLE:
1/22/2019
GENERAL ARRANGEMENT,
R7PT-12AK1 W/ LEVELWIND
SIZE:
-
S001960
SHT:SCALE:
DWG NUMBER: REV:
PART NUMBER:
1:16 OF
1
0
1
B
THIS DRAWING IS THE PROPERTY
OF RAM ITC. THE DESIGN AND DATA
SHOWN INCLUDES PROPRIETARY
INFORMATION THAT DESCRIBES
RAM ITC. PRODUCTS. THE
BORROWER BY RECEIPT AND
RETENTION OF THE DRAWING
AGREES, THAT EXCEPT AS
EXPRESSLY AUTHORIZED IN
WRITING BY RAM ITC., IT WILL (1)
ONLY USE THE DRAWING OR THE
DESIGN AND DATA SHOWN FOR THE
PURPOSE INTENDED BY RAM ITC; (2)
NOT LOAN, REPRODUCE, EXHIBIT OR
DISTRIBUTE THE DRAWING OR ANY
COPY OF THE DESIGN OR DATA
SHOWN FOR USE BY ANY OTHER
THAN RAM ITC., AND (3) UPON
DEMAND RETURN THE DRAWING,
ALL COPIES AND ALL MATERIAL
COPIES THEREFROM.
A A
REVISION HISTORY
REV DESCRIPTION DATE ECN
0INITIAL RELEASE
1/22/2019
-
NOTES:
1.
ALL DIMENSIONS ARE IN INCHES UNLESS OTHERWISE NOTED.
2.
WEIGHT OF UNIT W/O WIRE ROPE IS APPROXIMATELY 4,200 lbs.
3.
THE DRUM GUARDS AND LEVELWIND CAN BE ASSEMBLED SO AS TO ACCOMODATE A WROTA
(WIRE ROPE TAKE OFF ANGLE) RANGING FROM 0° (VERTICAL) TO 90° (HORIZONTAL).
DRUM GUARDS NOT SHOWN IN ALL VIEWS.
4.
SOME EQUIPMENT AND ACCESSORIES SHOWN ARE OPTIONAL.
8
1
2
15
7
16
19
38
56
3
16
3
4
22
53
15
16
12
DRUM
36 DRUM FLANGE
16 DRUM
WIRE ROPE
@ TOP RATED
LAYER
WIRE ROPE
@ BOTTOM
LAYER
LEVELWIND AUTO
AND MANUAL
CONTROL
61
7
8
20
1
2
33
55
6
1
8
1
3
4
11
1
2
11
1
2
11
1
2
38
1
1
2
22
1
2
41
19
DRUM
WINCH
1
1
8
HRU
AIR MOTOR
W/ DISC BRAKE
AIR INLET
ASSEMBLY
2 IN. NPT - FEMALE
AIR INLET
LEVELWIND
DRIVE MOTOR
THROTTLE
LEVER
LIFTING EYE
2.00
