1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
125
SURFACE
FINISH:
SURFACE FEATURES: MACHINED PARTS ONLY
T.I.R
.005 PERPENDICULAR .015
FLATNESS .010 PARALLEL
.015
4660
X.X ±0.03
X.XX ±0.015
X.XXX ±0.005
FRACTION ± 1/16
ON ALL
MACHINED
SURFACES
DIMENSIONS:
BREAK ALL SHARP EDGES
UNLESS OTHERWISE SPECIFIED:
ALL DIMENSIONS ARE IN INCHES
AND ALL TOLERANCES ARE AS STATED
3rd ANGLE PROJECTION
DO NOT SCALE
R7PT-12AK W/LW
LBS.
EST. FINISHED
WEIGHT
ORIGINAL JOB NO.
MODEL NUMBERNEXT ASSEMBLY
ANGLES: ±
0.5°
APVD:
M. WEHMEYER
M. TROYER
M. TROYER
2/19/2019
2/19/2019
CKD:
W. CULBERTSON
DWN:
ENG:
2/19/2019
TITLE:
2/19/2019
WINCH ASSEMBLY W/LW, CV3, AND
FRL, R7PT-12AK
SIZE:
AF82501
410625
SHT:SCALE:
DWG NUMBER: REV:
PART NUMBER:
NTS OF
1
0
2
B
THIS DRAWING IS THE PROPERTY
OF RAM ITC. THE DESIGN AND DATA
SHOWN INCLUDES PROPRIETARY
INFORMATION THAT DESCRIBES
RAM ITC. PRODUCTS. THE
BORROWER BY RECEIPT AND
RETENTION OF THE DRAWING
AGREES, THAT EXCEPT AS
EXPRESSLY AUTHORIZED IN
WRITING BY RAM ITC., IT WILL (1)
ONLY USE THE DRAWING OR THE
DESIGN AND DATA SHOWN FOR THE
PURPOSE INTENDED BY RAM ITC; (2)
NOT LOAN, REPRODUCE, EXHIBIT OR
DISTRIBUTE THE DRAWING OR ANY
COPY OF THE DESIGN OR DATA
SHOWN FOR USE BY ANY OTHER
THAN RAM ITC., AND (3) UPON
DEMAND RETURN THE DRAWING,
ALL COPIES AND ALL MATERIAL
COPIES THEREFROM.
3.6
3/4-10 X 2-1/2 HHCS
8FQ05026
-
5
.4
3/4 FLAT WASHER
8FQ12757
-
4
3.6
HOSE ASSEMBLY, 1-1/2 IN. HOSE W/ 1-1/2 MNPT ENDS, 40 IN. LG
1H952940409529-403
551.4
BASE PLATE, R7-AW2.8B MOUNTING ADAPTER
1
AR105974105972
4097.9
WINCH ASSEMBLY WITH LEVELWIND, R7PT-12AK
1
AF82201410622
1
Parts List
WT (LBS)
EXPANDED DESCRIPTIONDESCRIPTIONQTYPART NO.DRAW NO.ITEM
REVISION HISTORY
REV DESCRIPTION DATE ECN
0INITIAL RELEASE
2/21/2019
NA
NOTES:
3
4
5
2
TORQUE ALL FASTENERS ACCORDING TO RAM PROCESS SPECIFICATION PS-100013
WHERE APPLICABLE.
1.
1
1
