TITLE:
3/13/2019
ASSEMBLY, LEVELWIND CONTROL
VALVE
SIZE:
AR10684
410684
SHT:SCALE:
DWG NUMBER: REV:
PART NUMBER:
NTS OF
1
0
2
B
THIS DRAWING IS THE PROPERTY
OF RAM ITC. THE DESIGN AND DATA
SHOWN INCLUDES PROPRIETARY
INFORMATION THAT DESCRIBES
RAM ITC. PRODUCTS. THE
BORROWER BY RECEIPT AND
RETENTION OF THE DRAWING
AGREES, THAT EXCEPT AS
EXPRESSLY AUTHORIZED IN
WRITING BY RAM ITC., IT WILL (1)
ONLY USE THE DRAWING OR THE
DESIGN AND DATA SHOWN FOR THE
PURPOSE INTENDED BY RAM ITC; (2)
NOT LOAN, REPRODUCE, EXHIBIT OR
DISTRIBUTE THE DRAWING OR ANY
COPY OF THE DESIGN OR DATA
SHOWN FOR USE BY ANY OTHER
THAN RAM ITC., AND (3) UPON
DEMAND RETURN THE DRAWING,
ALL COPIES AND ALL MATERIAL
COPIES THEREFROM.
.2
MUFFLER, 1/2" NPTM2AG01401
-
6
4.7
VALVE, 4 WAY. 1/2" NPT SUB PLATE MOUNTING
1
FB38196
-
5
.1
-4 ORFS TO 1/8 NPT
2FP01383
-
4
.6
FITTING, RUN TEE, 1/2"-14 NPTF FEMALE X FEMALE X MALE
1
FP50387
-
3
.1
5/16-18 X 3/4 SHCS3FQ00386
-
2
1.5
SUBPLATE, LEVELWIND CONTROL VALVE MOUNTING
1
AG09130409130
1
Parts List
WT (LBS)
EXPANDED DESCRIPTIONDESCRIPTIONQTYPART NO.DRAW NO.ITEM
REVISION HISTORY
REV DESCRIPTION DATE ECN
0INITIAL RELEASE
3/13/2019
NA
4
APPLY LOCTITE 277 TO FASTENERS AS REQUIRED PER MANUFACTURERS INSTRUCTIONS.
1
NOTES:
6
5
6
3
2
5
