RAM R7 Series User Manual

OIM‐600056 Rev.0 6
2.1. GeneralSpecifications








GeneralSpecifications
Model
R7PT‐512AK1G
(AF82501)
AirSystem
RatedOperatingPressure 90psi(6.2 Bar)
AirConsumption@rated
performance
700scfm(19.8m
3
/min)
Controls
LocalControl‐Manual
Leverw/NeutralSafetyLock
andEmergencyStop
Customer
Connections

MotorAirInlet 1‐1/2NP
T
MotorExhaust 2‐1/2NP
T
ControlValveExhaust 1‐1/2NP
T
PhysicalParameters
EstimatedUnitWeight
(w/owirerope)
4,200lbs.(1,905kg.)

Overall
Dimensions
Length 62.0in(1,575mm)
Width 56.5in(1,435mm)
Height 54.0in(1,372mm)
Drum
Dimensions
BarrelDiam. 16.0in(406mm)
WorkingWidth 12.0in(305mm)
FlangeDiam. 36.0in(914mm)
Brakes
DrumBrake Automatic
DiscBrake Automatic
Accessories
Automatic
Levelwind
Max. FleetAngle +/‐ 6°
Min.FleetDist. 4.8ft(1.46m)
LinePull&SpeedRating
(AtRatedPressureand
Volume)
SeePerformanceChartforDetails
Personnel
N/A
N/A
Utility
(RatedLayer–8th)
15,500lbs.(7,030kg.)
42ft/min(12.8m/min)
Utility
(TopLayerDrum)
12,700lbs.(5,760kg.)
51ft/min(15.5m/min)
Max.Stall
(BareDrum)
41,200lbs.(18,688kg.)
WireRope
Minimum Maximum
RecommendedWire
Diameter
7/8in(22mm) 1in(26mm)
SpoolingCapacity
(ontopworking
layer)
990ft.(302m) 682ft.(208m)
Min.Recommended
BreakStrength
Maintain5:1SFoverheadliftingapplications


RAM R7 Series Specifications

General

Gear Train	3-Stage Planetary
Series	R7
Line Pull	7000 lbs
Remote Control	Wireless Remote
Battery Leads	2 gauge
Rope	3/8" Synthetic Rope
