After welding check flatness of the plate and mill surface as needed. Maximum
acceptable deviation from flatness is 1 mm (0.04 in)
Bottom plate recommended minimum
thickness (X)
25 mm (0.98 in)
Side plate recommended minimum
thickness (Y)
25 mm (0.98 in)
