Rancilio MD User Manual

36
3. TECHNICAL DATA (Fig.4)
Index (Fig.3):
1 Main switch;
2 Hand grinding button (MD50/AT – MD80)
3 Bean hopper container;
4 Grinders protection;
5 Hopper container closure lever;
6 Ferrule to adjust the grinding fineness;
7 Button to release the adjustment ferrule;
8 Ground coffee container;
9 Adjustment knob for ground coffee doses;
10 Delivery lever for ground coffee doses;
11 Fork to support the filter ring;
12 Coffee powder collecting tray;
13 Ground coffee press
14 Fork fixing screw
15 Coffee container cover
16 Dosing star
2.4. Protections
All moving parts are inside the machine.
In the bean container (3 - Fig.3) a protection (4) is
fixed with screws to protect your hands when filling
and cleaning the bean container.
2.5 Aerial noise
The result of the noise tests performed in accordance
with the regulations in force are as follows:
At the operator’s place with idling machine:
Leq (A)= < 70 dB(A)
At the operator’s place with operating machine:
Leq (A)= 75 dB(A)
2.6. Vibrations
The machine is supplied with rubber vibration sup-
pressing feet. In normal working conditions, the
machine does not produce vibrations harmful to the
operator and the environment.
Versioni MD40 MD50/ST - MD50/AT MD80
Machine dimensions mm L.140 - P.335 - H.440 L.155 - P.360 - H.405 L.200 - P.390 - H.610
Packing dimension mm L.535 - P.210 - H.345 L.585 - P.220 - H.405 L.535 - P.210 - H.405
Packing volume m
3
0,039 0,052 0,086
Net weight kg 9 13 18
Gross weight with packing kg 10 14 20
No. of items 1 1 1
Grinders diameter mm 50 63,5 75
Production kg/h 2,5 ÷ 3,5 7 ÷ 9 12 ÷ 14
Bean container capacity g 500 1000 1400
Gound coffe container
capacity
g 170 300 400
Doses adjustment g 5 ÷ 8 5 ÷ 10 5 ÷ 10
