10 OM-PT-W-L SERIES PREP TABLES
Parts List
TOP
ITEM SERVICE PART DESCRIPTION PT48-18W-L PT60-24W-L PT72-30W-L PT84-36W-L
T1 RP COV2101 PT48-18W ROLLCOVER ASSEMBLY, RQ ROLLPT48-18W X -- -- --
T1 RP COV2102 PT60-24W ROLLCOVER ASSEMBLY, RQ ROLLPT60-24W -- X -- --
T1 RP COV2103 PT72-30W ROLLCOVER ASSEMBLY, RQ ROLLPT72-30W -- -- X --
T1 RP COV2104 PT84-36W ROLLCOVER ASSEMBLY, RQ ROLLPT84-36W -- -- -- X
T2 RP ROL2101 ROLL COVER FRONT ONLY, PT48-18W, T07-2053 X -- -- --
T2 RP ROL2102 ROLL COVER FRONT ONLY, PT60-24W, T07-2068 -- X -- --
T2 RP ROL2103 ROLL COVER FRONT ONLY, PT72-30W, T07-2083 -- -- X --
T2 RP ROL2104 ROLL COVER FRONT ONLY, PT84-36W, T07-2103 -- -- -- X
T3 HD PIN0101 ROLL COVER PIVOT PIN, .875" X 1/4-20 X X X X
T4 FA NUT0403SS NUT, PIVOT PIN 1/4-20 CAP NUT X X X X
T5 RP BAR1204 PAN SUPPORT, 12 PAN OPENING, FRONT & BACK, 25.8”, T07-0087 -- X X --
T5 RP BAR1306 PAN SUPPORT, 18 PAN OPENING, BACK, 38.75”, T07-0088 X -- X X
T5 RP BRK1504 PAN SUPPORT. LEFT, T07-0085 X X X X
T5 RP BRK1505 PAN SUPPORT. RIGHT, T07-0086 X X X X
T5 RP BAR2107 PAN SUPPORT, 18 PAN OPENING, FRONT, 38.75”, T07-2161 X -- X X
T6 RP BAR069 ADAPTER BAR, 12" LOCKING X X X X
T7 RP BAR07K ADAPTER BAR, 20" X X X X
T8 RP CLP001 CLIP, CUTTING BOARD, SET OF 2 X X X X
T9 FA NUT0130 NUTSERT, 10/24 ALUM. X X X X
T10 HD PIN2030 PIN, CUTTING BOARD X X X X
T11 RP CPH1048 POLY CUTTING BOARD, 10" X 48" X .375" X -- -- --
T11 RP RCH1048 RICHLITE CUTTING BOARD, 10" X 48" X .5" X -- -- --
T11 RP CPH1060 POLY CUTTING BOARD, 10" X 60" X .375" -- X -- --
T11 RP RCH1060 RICHLITE CUTTING BOARD, 10" X 60" X .5" -- X -- --
T11 RP CPH1072 POLY CUTTING BOARD, 10" X 72" X .375" -- -- X --
T11 RP CRH1072 RICHLITE CUTTING BOARD, 10" X 72" X .5" -- -- X --
T11 RP CPH1084 POLY CUTTING BOARD, 10" X 84" X .375" -- -- -- X
T11 RP CRH1084 RICHLITE CUTTING BOARD, 10" X 84" X .5" -- -- -- X
