12 OM-RCS-24 SERIES CHEESER STATION
Parts List
GRILL DOOR ASSEMBLY
CALL FACTORY FOR REPLACEMENT PARTS:
888-994-7636
ITEM QTY SERVICE PART DESCRIPTION
29 1 RP DOR2101 CONDENSING UNIT DOOR CHEESER UNIT LT HINGED REPLACEMENT PART
30 1 RP DOR2102 CONDENSING UNIT DOOR CHEESER UNIT LT HINGED SHEET-METAL ONLY
31 1 HD HDL0103 HANDLE, RECESSED DOOR PULL BLACK PLASTIC
32 1 FA NUT0124 NUTSERT, 1/4-20 ALUM KPNG RIVNUT
33 1 HD PIN020B PIN, 7/16x5/8"W/SCW BOLT ONLY J32-X002
34 1 HD PIN020P PIN, 7/16x5/8"W/SCW PIN ONLY J32-X001
35 1 RP DOR2103 HINGED DOOR MNTING BRACKET HINGED LEFT REPLACEMENT PART
36 7 FA SCW3075T SCREW, 10x3/4"THP SMS SS
37 1 FA BLT4062 BOLT, 1/4-20x3/4" H/H/B 18-8 HCYK HEX HEAD BOLT STAINLESS
38 1 HD CTH9901 CATCH, MAGNETIC SOUTHCO 02-10-201-10
* = NOT SHOWN
