Rane AC23S - Technical Specifications

81
Technical Specifications
Parameter Specification Limit Units Conditions/Comments
Crossover: Alignment
Slopes: (3-way)
Range: (3-way)
Range: (3-way)
Range: (2-way)
Time Delay Adjust Range
Inputs: Impedance
Maximum Level
Gain Range
Inputs: Type
Outputs: Type
Impedance
Maximum Level
Gain Range
Band Muting Switches
RFI Filters
Infrasonic Filter
Ultrasonic Filter
Frequency Response
THD+Noise
IM Distortion (SMPTE)
Signal-to-Noise Ratio
Maximum Power
Linkwitz-Riley
24 dB per Octave
70-1 kHz Low to Mid
190-7 kHz Mid to High
190-7 kHz Low to High
Off to +2
20k
+21
Off to +6
Active Balanced XLR
Active Balanced XLR
200
+20
Off to +12
Yes
Yes
20 Hz, 18 dB/Oct, Butterworth
40 kHz, 18 dB/Oct, Bessel
20-40 kHz
0.02
0.02
92
7
5%
1%
1
-0/+4
1%
1
-0/+4
3%
3%
+0/-3
.01
.01
2
ms
Ω
dBu
dB
Ω
dBu
dB
Hz
Hz
dB
%
%
dB
W
Proprietary 4
th
-order state-variable
41 detent continuously variable pot
as above
as above
Low & Mid outputs only
Pin 2 hot per AES standards
Pin 2 hot per AES standards
600 Ω or greater
Low and Mid outputs only
Linear Phase
+4 dBu, 20 kHz noise bandwidth
60 Hz / 7 kHz, 4:1, +4 dBu
re +4 dBu, 20 kHz noise bandwidth
Universal Line Voltage
Construction
Size (w x d x h)
100-240 VAC, 50/60 Hz
All steel
19.0” x 5.3” x 1.8”
48.3 x 13.3 x 4.4 cm
V
AC 7W
Note: 0 dBu= 0.775 Vrms
Specifications are subject to change without notice.
