SPECIFICATION
FUNCTION
1. Line/PC - (3-way toggle switch) [MIDI] Channels:
This selects playback audio to mix with. Audio in is always routed over USB directly to the computer
from the input When in
“PC 1” the audio will be routed from the software to the channel. This is for USB A host.
“Line” routes rear inputs to channels 1 & 2 of the mixer.
“PC 2” the audio will be routed from the software to the channel. This is for USB B host.
2. Gain – (270-degree Pot) [MIDI]:
This pot controls the gain for its associated channel on the mixer.
3. Treble – (270-degree Pot w/ Center Detent) [MIDI]:
This knob controls the high-end treble output of its associated channel on the mixer.
Full left is – infinity kill and right is +6db gain .
4. Mid – (270-degree Pot w/ Center Detent) [MIDI] :
This knob controls the Mid-range frequency of its associated channel on the mixer.
Full left is – infinity kill and right is +6db gain.
5. Bass – (270-degree Pot w/ Center Detent) [MIDI] :
This knob controls the low end bass frequencies of its associated channel on the mixer.
Full left is – infinity kill and right is +6db gain .
6. Filter (270-degree w/Center Detent) [MIDI] :
This center Detented knob acts as a low pass filter from center sweeping left and a high pass filter from center
sweeping right. A pre-determined amount of resonance will be applied. The filter will always be active but only
audible once it has been moved past its 12 o’clock positioning. This is spec’d as a hardware filter.
7. Channel Fader (45mm Slide Fader) [MIDI]:
This is the volume controller for the channel. Channel faders are not user replaceable.
8. Cross Fader [MIDI]:
This fader is for transitioning from Left assigned (A) Cross fader Deck Position to Right assigned (B) Cross
fader Position.
This is a user-removable cross fader so the mechanical design must be screwless around the fader but
still allow replacement.
The crossfader will also support standard faders as drop-in replacments. Innofader or Numark CP Pro.
