RANE SIXTY-TWO MIXER FOR SERATO SCRATCH LIVE • DATA SHEET
2
Sixty-Two Mixer Controls
Battle Bridge Mounting Accessory
“68 EARS 14” battle bridges for the Sixty-Two
bring the total width of the mixer to 12" (30.5 cm)
for cofn mounting. These measure 14" x .75" x
3" (35.8 x 1.9 x 7.7 cm).
CUE
PGM 1
CUE
USB AUX
CUE
PGM 2
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
HIGHLOW
10
0
2
4
8
6
MAINCUE
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
10
0
2
4
8
6
RIGHTLEFT
+6OFF
+6OFF
+6OFF
+6OFF
+6OFF
+6OFF
+6OFF
+6OFF
HIGHLOW
RIGHTLEFT
HIGHLOW
B B
A A
PGM 1MIC
DECK 1
AUX
SP-6 ASSIGN ON OVER
HIGH
LEVEL
LOW
FLEXFX
INSERT
TIME TAP
CUES 1 2 3 4 5
C D
543
SAMPLES 4 5 6321
21
BA
ON
CUE
EXT. INSERTFILTER
BEAT
FLANGER PHASER ECHO ROBOT REVERB
FLEXFX
BACK
LOAD
SCROLL
LOOPS
BARS
SELECT
DELETE
LEVEL
FILTER
FLEXFX
AUTO MANUAL
LOOP IN
ROLL OUT
SAVE LOOP
PGM 2 MIX DECK 2
LEVEL
PHONES
SP-6 ASSIGN
BACK
LOAD
SCROLL
LOOPS
BARS
SELECT
DELETE
LEVEL
PAN
SPLIT CUE
MANUAL AUTO
IN LOOP
OUT ROLL
LOOP SAVE
LOW
MID
HIGH
LEVEL MAIN
SESSION OUT
SESSION IN
BOOTH
LOW
DEPTH
MID
HIGH
PH / CD PH / CD
SOURCE
PAN
1 2
FILTER
FLEXFX
SOURCE
PAN
3 4
FILTER
FLANGER -Fb
BPM:120 * 4:1
2000 ms
Mic Input has switchable Mic or Line-level with
2-band full-cut tone and pan controls.
The Mic can route to FlexFX or record to USB.
Mic Over ducks other PGM sources by 12 dB.
Two Program buses:
• Select either USB port for playback and MIDI.
• Four Phono / Line Inputs.
• Left / Right Pan.
• 3-band full-cut tone controls.
• Sweepable Low / High-pass lter.
Two USB ports, each with six stereo
record channels and four stereo playback
channels simultaneously available, allows
two DJs with their own laptops to share
the mixer. The button assigns the SP-6
sample player to the indicated USB port.
Level controls on each Output:
• Main Output on XLR jacks.
• Booth Output on 1/4" TRS.
• Session Output on RCA.
The Crossfader and channel faders are no-noise,
no-bleed, no-contact magnetic faders.
FlexFX are stackable:
•
Six internal effects with
seamless on-beat switching
between effects.
•
External Insert engages the
external analog Effects Loop.
• Insert engages software
effects through USB.
Aux Input is from the USB
playback stereo pair 5-6,
usually from the SP-6 sample
player. You can sweep the
Low-pass / High-pass lter and
use FlexFX on samples.
Contour controls adjust the faders and the
Crossfader for a smooth transistion or a fast cut.
True Split Cue for any Program
bus or the FlexFX submix with
effects to the front panel 1/4"
and 3.5 mm headphone jacks.
Cues button = amber: Recall
Cue Points with “Hot Cue”
behavior in Scratch Live.
Samples button = red: Play
samples from the SP-6 sample
player in Scratch Live.
In Auto mode, Loop buttons
use the Scratch Live auto-
loop, lighting the buttons
orange. In Manual mode, Loop
buttons use manual looping
features, lighting the buttons
green. Select knob adjusts the
loop length.
Back buttons shift between
crates & tracks. Scroll knob
scrolls crates & tracks, click it
to load the track to a deck.
The FlexFx Loop can create a
sub-mix with any combination
of the two Program buses, Mic,
and USB feed, and then add
internal or external effects. This
submix may be recorded via
the USB Send, or output by the
analog FlexFx Loop Send.
MIDI mapping is done for you
as the Sixty-Two is plug-and-
play with Serato Scratch Live.
Advanced users can custom
map most mixer controls to
many other third-party audio
programs. The MIDI control as-
signments are in the Sixty-Two
Manual.
Z-Trip Edition Sixty-Two Z Mixer
Z-Trip’s Limited Edition Sixty-Two Z Mixer is
functionally identical to Rane’s Sixty-Two with
added bonuses:
• Face plate design by Shepard Fairey.
• Includes high-quality custom purple cables.
