FUSE DETAILS
RANGE ROVER 2.3
PASSENGER COMPARTMENT FUSE BOX
Link Rating Vehicle Function
FL1 80 A All Heated front screen relay.
FL2 60 A Td6 Ignition switch.
FL2 60 A V8 Engine immobilisation ECU, header 499.
FL3 50 A All Light Check Module.
FL4 50 A All Light Check Module.
FL5 100 A All MF17, MF18, MF19, F1, F2, F3, F4, F6, F7, F9,
F10, F11, F12, F13, F14, F15 and F16 of the rear
fuse box.
F31 F1
F32 F2
F33 F3
F34 F4
F35
F5
F36
F6
F37 F7
F38
F8
F39
F9
F40
F10
F41
F11
F42
F12
F43
F13
F44
F14
F45
F15
F46
F16
F47
F17
F48
F18
F49
F19
F50
F20
F51
F21
F52
F22
F53
F23
F54
F24
F55
F25
F56
F26
F57
F27
F58
F28
F59
F60
F29
MF61
MF62
MF63
MF64
F30
M86 5908
