Range Rover L322 - Page 21

FUSE DETAILS
2.4 RANGE ROVER
Fuse Rating Vehicle Function
F1 5 A All Instrument pack
F2 5 A All Heated rear screen relay, rear blower motor relay,
seat heat relay, relay 2, F5 and F8 of the rear fuse
box.
F3 7.5 A All Fuel cooling fan motor.
F4 5 A All Light Check Module, Door lamp module.
F5 7.5 A All Diagnostic socket, EAT ECU.
F6 5 A All Tyre Pressure Monitoring ECU, Interior mirror, Park
Distance Control ECU.
F7 5 A All Not used.
F8 5 A All Radio/cassette player.
F9 5 A All Light Check Module, Brake pedal switch, Rotary
coupler.
F10 15 A All Horn relay.
F11 30 A All Drivers door module.
F12 10 A All HeVAC control unit.
F13 5 A All Transmission selector indicator lamp, Steering
angle sensor, Clock.
F14 5 A All Not used.
F15 5 A All Diagnostic socket, BCU.
F16 5 A All Tyre Pressure Monitoring ECU.
F17 5 A All Door lamp module.
F18 10 A All Engine immobilisation ECU, Steering column
interlock ECU.
F20 30 A All LH seat switch pack.
F21 30 A All RH seat switch pack.
F22 7.5 A All Telephone module.
F23 15 A All Steering wheel relay.
F24 30 A All Passenger door module.
F25 5 A V8 Ignition switch.
F26 30 A All Windscreen wiper delay ECU.
F27 20 A All BCU.
F28 30 A All Headlamp wash/wipe relay.
F29 10 A All Steering wheel heater ECU.
F30 15 A All Not used.
F31 5 A All ECM, Steering column interlock ECU.
F32 5 A All LH Xenon headlamp, RH Xenon headlamp.
F33 5 A All Transfer box ECU.
