Range GM Refresh RA007 - Page 10

10
Installation Cont’d
STEP 5 - Install the Range module onto the ECM while making
sure the spring-loaded latch locks to the ECM.
Range Logo
CAUTION: Make sure the Range module is fully seated on the
ECM by verifying the position of the spring-loaded latch beneath
the module. The latch should be sitting proud of the range module
when fully seated.
Sticks out
Overhangs
Unlocked Locked
Locked
