8
Installation Cont’d
STEP 3 - On the front left wheel well,
remove the six T-15 Torx Screws
securing the front half of the fender
liner to the wheel well. Then, pull the
fender liner up/back to access the
ECM.
STEP 4 - Locate the ECM towards the front of the wheel well and
disconnect the lowest connector.
To avoid damaing the connector, follow the instructions shown
below and on the next page. A pick tool may make this process
easier.
Pull the red locking tab outward as shown below.
To Next Page
