Schlagmäher - Tondobroyeuse - Flail Mower- Rasaerba a trincia
Pos. Code Dimension Beschreibung Description Description Descrizione
RT80 RT100
1 1 1 293090 Gehäuse Boîtier Housing Carter
2 1 1 293091 Distanzbüchse Entretoise Collar Distanziale
3 1 293095 Rohr Tube Tube Canotto
3 1 293096 Rohr Tube Tube Canotto
4 1 1 293097 8x8 Gewindestift Cheville filetée Stud Grano
5 1 293100 Welle Arbre Shaft Albero
5 1 293101 Welle Arbre Shaft Albero
6 4 4 31189 10.2/16.1x1.6 Federring Rondelle Washer Rondella
7 1 1 293102 Antriebswelle Arbre de trasmission Drive shaft Albero entrata
22 1 1 293104 Z=10 Kegelradwelle Pignon Shaft, pignon Pignone
27 4 4 16448 6205 Kugellager Roulement Ball bearing Cuscinetto
28 2 2 52744 25X52X7A Simmerring Bague d'étanchéitée Oil seal Paraolio
29 2 2 15735 D472 52X2 Seegerring Circlip Retaining ring Seeger
30 2 2 15704 D471 25X1.2 Seegerring Circlip Retaining ring Seeger
31 1 1 90968 D910 R3/8" Verschlussschraube Bouchon de fermeture Plug drain Tappo carico olio
32 2 2 16337 D6885 A6X6X36 Keil Clavette Key Linguetta
39 4 4 17979 D933 M10X25 Schraube Vis Screw Vite
55 1 1 293105 Dichtung Joint Gasket Guarnizione
56 1 1 12858 6304 Kugellager Roulement Ball bearing Cuscinetto
62 1 1 293106 Klauenmuffe Manchon à griffes Clutch, one way Innesto ruota libera
63 1 1 293107 Druckfeder Ressort de pression Spring compression Molla
66 1 1 34951 D988 25X35X0.5 Passscheibe Cale Washer, plain Spessore
67 1 1 293108 Z=30 Tellerrad Couronne Crown wheel Corona
68 1 1 57952 D988 25X35X2 Passscheibe Cale Washer, plain Spessore
